NDT-520

IDEAL TOOL FOR…

Powder Coaters

Paint Suppliers

Paint Applicators

Coating Quality Control Inspectors

Painting Contractors

Automotive Dealers

Automotive Refinishers

Automotive Resellers

Body Shops
Car Dealerships & Inspectors and more…

§ Measures coatings on ANY METAL including steel, aluminum (including Anodizing on Aluminum), brass, etc. Automatically recognizes the material and takes an accurate measurement.

§ Automatic ON/OFF switching.

§ Automatic Substrate Recognition.

§ Factory calibrated and ready for use. Measures precisely right out of the box.
Simple operation: No user calibration required.

§ ZERO set feature for non-standard surfaces.

§ RESET to default restore factory settings feature when no zero reference is available.

§ Strong, wear and weather resistant probe.

§ Large 2 LINE HIGH CONTRAST FLIP LCD Display for easy viewing in any position.

§ Durable high quality construction.

§ Fast and accurate measurements with sound tone confirmation.

§ Mils / Microns selectable. Displays readings in Metric (μm) or Imperial units (mil).

§ Pocket-sized and lightweight for comfortable one hand operation.

§ Supplied with a set of plastic test shims.

§ Works with a single AAA battery.

§ Built-in dual Fe / NFe probes.

§ Set of plastic test shims and 2 reference calibration plates (Steel and Aluminum).

§ Hard shell storage case.

§ Custom horizontal leather holster case with a secure belt clip and dual magnetic locks.

§ AAA industrial alkaline battery.

§ Instruction manual.

Fe-Probe:                                     Measurement on Steel or iron

NFe-Probe                                    Measurements on Aluminum ( or any Non-Ferrous metal )

Range:                                          0-50 mils ( 0.0 to 1250µm

Resolution                                     0.1mils ( 2µm) high resolution

Accuracy                                       ± [(1%~3%)H+1um]

Temperature range:                     Storage: -10°C to 60°C (14°F to 140° F

                                                     Operation: 0° C to 60° C (32° F to 140° F)

Power Supply                               Battery: 1 x 1.5V AAA Alkaline

Dimensions                                   4.2″ x 1.7″ x 0.9″ in. (110 mm x 45 mm x 23 mm)

Weight                                          2.7 oz. (70 g) Including batteries
